The Holtek HT32F67593 device is a high performance, low power consumption 32-bit microcontroller based around an Arm® Cortex®-M0+ processor core. The Cortex®-M0+ is an energy-efficient processor core which is tightly coupled with a Nested Vectored Interrupt Controller (NVIC), SysTick timer, and includes advanced debug support.
The device operates at a frequency of up to 64 MHz with a Flash accelerator to obtain maximum efficiency. It provides up to 1024 KB encryptable in-system Flash memory for code/data storage, and up to 128 KB of embedded SRAM memory for system operation. A rich set of peripherals is implemented in the device, including communication interfaces such as UART×2, QSPI×1, I²C×2, SCI×1, and I²S×1. Additionally, the device features QEI×1 and TSEN×1 (Temperature Sensor) for advanced control and sensing, along with hardware-based security modules including AES128×1 and TRNG×1 to ensure data integrity and secure transmission. Several power saving modes provide the flexibility for maximum optimization between wake-up latency and power consumption.
The above features ensure that the device is suitable for use in a wide range of BLE products such as Continuous Glucose Monitors (CGM), handheld healthcare products, smart device information beacons, data loggers, and human interface devices.
Features
High-Performance Low-Power Core
- - 32-Bit Arm® Cortex®-M0+ Processor: Operates up to 64 MHz, delivering energy-efficient processing for wearable applications.
- - Massive Memory Resource: Equipped with 1024KB Flash and 128KB SRAM, providing ample space for complex algorithms, long-term data logging, and OTA firmware updates.
Robust Wireless Connectivity
- - Long-Range BLE Radio: High-performance RF transceiver with +10dBm Output Power and -96dBm Sensitivity, ensuring stable connections even through clothing or body interference.
- - Secure Transmission: Integrated AES-128 hardware encryption and TRNG (True Random Number Generator) protect sensitive medical data.
Rich Peripheral Integration
- - Versatile Interfaces: Includes UART×2, I²C×2, SPI/QSPI×1, and SCI×1 (Smart Card Interface) for flexible system expansion.
- - Audio & Sensing: Features I²S Interface for audio applications and an integrated Temperature Sensor (TSEN).
- - Precision Control: Built-in Quadrature Encoder Interface (QEI) and 12-bit SAR ADC.
Optimized for Wearables
- - Ultra-Compact Package: 28-pin LGA (3mm × 3mm) footprint, perfectly matching the sensor AFE for extreme miniaturization.
- - Wide Voltage Range: Supports 1.8V ~ 3.6V operation, compatible with various battery chemistries.
